ez@zuoyeal.com Analyzer Characteristics
TPF100 temperature pressure flow rate integrated monitor uses pitot tube differential pressure method to measure flue gas velocity, and can directly measure flue gas pressure and temperature, which greatly improves the measurement accuracy and accuracy, and reduces the use cost and maintenance workload, especially suitable for online real-time measurement of flue gas parameters.
Technical Parameter
| TPF100 | Temperature | Pressure | Flow Rate | Humidity |
| Principle | PT100 | Polysilicon | Pitot tube | Zirconia |
| Range | 0-400℃ | -10~10Kpa | 5~40m/s | 0~40% |
| Accuracy | ≤±0.5%F.S. | ±0.5% | ≤±1%F.S. | ≤±1.5%F.S. |
| Analog Output | 4~20mA | 4~20mA | 4~20mA | 4~20mA |
